Farmall JXM

2 models from 80 HP to 88 HP.
The new Case IH Farmall JXM Series tractors deliver the power and performance that the owners expect, all featuring the distinctive Case IH premium design. Farmall JXM tractors are best in class in their farming segment while the straight rear axle design is perfectly tailored for transport operations. Depending on the need, Farmall JXM is available with 2WD or 4WD front axle versions and features a wide range of transmission options.

Overview

More Power.
More Options.
More Comfort.

Explore the series

Specifications

Model
Farmall JXM 80
Farmall JXM 90
Number of cylinders
4
4
Type
Turbocharged Aftercooled
Turbocharged Aftercooled
Emission Level
Tier 3
Tier 3
Capacity (cm³)
3,908
3,908
Maximum engine power with Power Management (hp (kW))
Maximum engine power (hp (kW))
@ engine speed (rpm)
Rated engine power with Power Management (hp (kW))
Rated engine power (hp (kW))
80 (60)
90 (67.2)
Rated engine speed (rpm)
2,300
2,300
Maximum torque Power Management (Nm @ rpm)
Maximum torque (Nm @ rpm)
310 @ 1400
340 @ 1400
Torque rise Standard and Power Management (%)
Fuel tank capacity diesel / urea (litres)
90 (-)
90 (-)
Transmission Type
12 x 12 Synchromesh gears + Power Shuttle
12 x 12 Synchromesh gears + Power Shuttle
Maximum Speed Forward (kp/h)
Powershuttle
Std.
Std.
Creeper
Option.
Option.
Transmission Type
8 x 8 Synchromesh gears + Power Shuttle
8 x 8 Synchromesh gears + Power Shuttle
Maximum Speed Forward (kp/h)
Powershuttle
Std.
Std.
Creeper
Option.
Option.
Transmission Type
20 x 20 Synchromesh gears + Power Shuttle
20 x 20 Synchromesh gears + Power Shuttle
Maximum Speed Forward (km/h)
Powershuttle
Std.
Std.
Creeper
Std.
Std.
Transmission Type
Maximum Speed Forward (km/h)
Powershuttle
Creeper
PTO Type
Reversible / Ground Speed
Reversible / Ground Speed
Speed Standard @ rpm
540 / 540E
540 / 540E
Speed Optional @ rpm
1,000
1,000
Ground drive
Shaft type
Speed Standard @ rpm
Front hitch lift capacity
2WD
Yes
Yes
4WD
Yes
Yes
Front axle suspension
Steering angle (°)
Min.turning radius (m)
Rear axle diff-lock
Service Brake Type
ABS Anti-lock braking system
System Type
Max. pump flow rate Standard / Option
54
54
System pressure (bar)
Control type
Max. lift capacity (kg)
2,500
2,500
OECD lift capacity through range @ 610 mm (kg)
Max. number of rear remotes valves
3
3
Max. number of mid mount valves
3
3
Remote valve timer control
Category type
I-II
I-II
Slip control
