A simple system to create a high-strength loop knot
TwinePro is the new patented knotter innovation by Case IH available on Large Square Balers (LB4 XL, LB6 HD and LB4 XLD series). Mounted in a stronger frame to withstand higher plunger loads, and featuring electric knotter fans to keep the units clean, the six TwinePro knotters use a simple system to create a high-strength loop knot. This allows the operator to achieve maximum density with a wide range of twines without the risk of bales bursting.
PRODUCTIVITY & DENSITY
Unparalleled packing performance
Up to 30% stronger loop knot
TwinePro combines Deering and Loop knots in a sequence with just one cut. Once the first standard knot is tied, a second knot – the loop knot – is tied for additional bale security. Compared to a single knotter system, twine is not held during the bale formation process with the double knotter system.
Increased daily productivity through greater bale efficiency
Strain on knotter components is eliminated and less pressure is exerted on the twine. TwinePro provides maximum tying reliability and maximum twine tensile strength while ensuring lower risk of exploding bales even at high bale density. Snapping twine and unrolling knots are a thing of the past.
Prevention of animal feed contamination
Strain on knotter components is eliminated and less pressure is exerted on the twine. TwinePro provides maximum tying reliability and maximum twine tensile strength while ensuring lower risk of exploding bales even at high bale density. Snapping twine and unrolling knots are a thing of the past.
Save time and increase profitability
Make your work easier while reducing your costs. Thanks to the high tensile strength of the system, only 6 twine strands are needed to guarantee best bale stability even at highest bale densities (200 kg/m³ and more).
- Cost savings — TwinePro eliminates offcuts left loose on the bale and in the field. In addition, less damage is left on the twine, which reduces the overall costs.
- Less knotter maintenance — the system prevents knotter misties due to the twine ends (no need to jump off your tractor). You'll do far less re-baling.
- Lower transport costs — thanks to the high density of the bales, you'll be able to produce fewer bales per hectare, which reduces handling requirements.
Choose from our three large square balers to best fit your requirements
TwinePro is available on the LB4 XL, LB6 HD and LB4 XLD series.
Large Balers LB4 XL series
- 4 models – Bale dimensions 80x70 to 120x90 cm
- Minimum PTO power: 75-150 hp
- Pick-up width: 1.968 / 2.352 m
- Number of knives: 19 - 29
Large Balers LB436 HD Series
- 1 model – Bale dimensions 120x90 cm
- Minimum PTO power: 250 hp
- Pick-up width: 2.352 m
- Number of knives: 29
Large Balers LB4 XLD Series
- 2 models – Bale dimensions 120x70 cm
- Minimum PTO power: 140 hp
- Pick-up width: 2.35 m
- Number of knives: 15 or 29
